Reverse Parking Space Query Kiosk

Reverse Parking Space Query Kiosk

1.Model:ZOJE-SP32(32inch)
2.Entrance deployment .Easy car search access
3.License plate input .Map-guided precise pickup
4.Touchscreen operation.Simple user-friendly use
5.Fast positioning.Cuts pickup time
6.System docking.Real-time data sync
7.Graphic interface.Intuitive clear display
8.Universal adaptation.Flexible layout.
  • Face to Face Discussion
  • Quality Assurance
  • 24/7 Customer Service

Product Introduction

Reverse Parking Space Query Kiosk for Smart Parking Systems — Faster Car Finding, Less Garage Congestion

Every job this terminal does comes down to parking management in large facilities. The Reverse Parking Space Query Kiosk (Model: ZOJE-SP32, 32-inch) is built for that. Garage entrances get one. So do elevator lobbies and busy crossings. In multi-level buildings GPS often fails, and that is where drivers lose their car. This kiosk fixes that. A license plate goes in on the touchscreen. Live LPR camera data then tells the system the exact spot, and a 2D or 3D route appears. The database holds more than 10,000 vehicles. Most lookups take about 2 seconds.

What Is This Product?

This kiosk is one terminal in the Reverse Car Searching System (RCSS). Video parking guidance cameras feed it data. License Plate Recognition (LPR/ANPR) nodes do the same. TCP/IP protocol carries the link. Crowded garages that span several levels get mapped this way, car by car.

Standard payment machines do another job. A vehicle-location interface is all this kiosk is. It looks up where a parked car sits. From its own fixed spot it then works out the best route to that slot. Guidance comes node by node, turn by turn.

Airports, shopping malls, and transit hubs are big sites. They see a clear gain. Drivers spend less time hunting for their car. Parking spaces then turn over faster. Garage aisles also get less crowded with people walking around.

Key Features

32-Inch Touchscreen Display

Inside the ZOJE-SP32 there is a projected capacitive touch panel. It reacts in under 10ms. The graphical interface needs no instruction reading first. Anyone can just use it.

Fast Vehicle Positioning

Less than 2 seconds pass before answers come back. Even with more than 10,000 vehicles in the parking database, that still holds true. Pickup times during peak hours get shorter because of this.

Fuzzy Search Capability

Mud or a bad camera angle can stop the system from reading a full plate. Partial plate matching still works in that case. Staff can also search a chosen time segment. Unclear vehicle images land in a gallery, and someone picks the right one by hand.

Real-Time Data Synchronization

Updates reach the kiosk over TCP/IP from the central parking management server. Recent map data also sits on the device in premium models. A short network drop then still leaves static navigation working. For full redundancy, add 4G backup connectivity.

Industrial-Grade Enclosure

Dust cannot get into the powder-coated cold-rolled steel housing. Humidity stays out too. Knocks bounce off it. IP ratings run from IP54 to IP65. Units keep working from -20°C to +60°C, so 24/7 use in basements and semi-outdoor sites is no problem.

Universal Layout Adaptation

Floor plans for a Reverse Parking Space Query Kiosk can be set up in more than one way on this system. So it works on a single-level lot. It also fits buildings with several floors and complex layouts.

Technical Specifications

Feature Specification
Model ZOJE-SP32 (32inch)
Input Device 32-inch Touch Screen
Touch Durability 60+ million touches
Network Interface RJ45 Ethernet
Control Interface USB
Power Requirements AC220V±10%
Power Consumption ≤200W
Dimensions 820×500×1350mm
Processor 32-bit ARM Industrial Grade
Operating Temperature -20°C to +60°C
Protection Rating IP54 to IP65

Quality Control Standards

Before a unit ships, it passes through several stages of inspection.

Display and Touch Panel Inspection: Each screen is checked for dead pixels, and none are allowed through. Touch response then gets a 10-point drift test. Sensitivity has to come in below 10ms over the whole screen surface.

Environmental Stress Screening (ESS): Every unit gets thermal cycling. This mimics the temperature swings of a garage. Humidity testing also runs at up to 90% RH. The goal is to check how well the unit resists motherboard corrosion and screen fogging.

Electrical Safety and Interface Testing: Before shipment, three checks are done. Leakage current gets measured. Grounding continuity gets verified. TCP/IP communication stability also gets tested under high data load.

Units are rated with an MTBF of ≥ 50,000 hours and meet IK07/IK08 impact resistance standards for the protective tempered glass, and IP54–IP65 dust and humidity protection.

certification

Reverse Parking Space Query Kiosk Application Scenarios

Mega-Commercial Complexes and Shopping Malls

You will find these kiosks in elevator lobbies. They also stand at busy crossing points on several underground levels. From there they send people to the parking zone they need. The quickest elevator or escalator is the route shown.

International Airports and Transit Hubs

Drivers on a long stay who forget their plate number can look the car up by entry time. Multi-system sites are what the kiosk was built for, and it runs next to the other terminals in the facility.

Smart Hospital Parking Facilities

In hospitals the interface can be set to high contrast, which makes it easier to read. The housing has been tested against frequent cleaning. Heavy daily use is covered too.

application

Customization and OEM/ODM Services

Hardware and software can both be customized by ZOJE to suit different project needs. That covers screen size changes and UI language changes. It also covers hooking up payment modules, for example NFC or QR code readers. Facial recognition and Bluetooth Beacon upgrades can be added too, if you ask for them.

We work with clients on OEM and ODM terms. Orders from stock usually ship in 5–7 days. Customized orders for Reverse Parking Space Query Kiosk need 10–15 days. Goods can go by sea or by air. DDU and DDP trade terms are both on offer.

Each product ships with a 2-year warranty. You also get help with installation. Long-term maintenance support comes with it too.

Have a project in mind and you want to see how this product fits? Send us a note at info@zoje-tech.com. We can talk you through the technical details. Or we can build a custom quote for you.

FAQ

Q: What happens if the kiosk cannot read a license plate?

A: Say the LPR camera missed a clear plate. In that case the system gives you a Fuzzy Inquiry or a Time-Segment Search. Type in a rough entry time, or pick the car out of a gallery of unidentified vehicle images from that window.

Q: What happens if the central server goes offline? Will the kiosk still work?

A: A live server connection is needed for real-time queries on standard models. On premium industrial units, recent map data sits on the device itself. Static navigation keeps showing because of that. Want full redundancy? Add a 4G backup link.

Q: How often does the touchscreen need servicing in a dusty garage?

A: Screens built for industry have sealed bezels. Once a month, wipe the outside with a cleaner that will not scratch the surface. If a unit runs an active cooling fan, clear the dust from inside twice a year. Fanless designs need less of that work.

Q: Does the kiosk support payment functions?

A: Location querying and navigation are the main job. On many units, you can set up hybrid kiosks with NFC or QR code payment modules. Kiosks built only for queries are often the pick in busy zones, so queues do not back up.

Q: How accurate is the route guidance?

A: The kiosk sits in a fixed spot. From there it works out a static path to the parking slot ID location. Directions come node by node, turn by turn. How accurate the guidance is depends on correct installation. Proper node mapping counts too. The floor plan configuration has to be current as well.

Q: What protection ratings should buyers verify?

A: A few figures matter most here. Look for MTBF ≥ 50,000 hours. Tempered glass should carry an IK07 or IK08 impact rating. Dust and humidity protection needs to sit at IP54–IP65. Ask the supplier for test reports that back up those numbers.
