Video Parking Guidance Zone Controller
2.Full-data collection.Network platform sync
3.Centralized control | Unified device command
4.License plate archiving. Enables reverse car-finding
5.Wireless deployment. Labor cost saving
6.Flexible expansion.Copes with lot upgrades
7.Stable RF signal .Anti-interference
8.24/7 tech support and service
- Face to Face Discussion
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Video Parking Guidance Zone Controller for Smart Parking Systems
The Video Parking Guidance Zone Controller (Model: ZOJE-02ZV) is an industrial-grade edge computing device developed by Hong Kong ZOJE Intelligent Technology Co., Ltd. Positioned between frontline video detectors and the central management server, it manages 32 to 64 sensor nodes per unit. The device supports full-data collection, wireless deployment, license plate archiving with reverse car-finding, and an offline standalone mode — designed to keep parking guidance running reliably even when the central server is unavailable.
What Is This Product?
This unit does edge computing. It sits between the parking cameras and the backend server. Occupancy data gets collected here. Power is distributed from the same box. Local logic runs on it too. So your system keeps working even when the server drops offline.
Data is processed at the edge. Only the essential metadata travels upstream. There are no continuous raw video feeds. That cuts bandwidth use on the facility network. License Plate Recognition (LPR) metadata is handled by the controller. LED zone displays get driven on site through RS485 interfaces. Occupancy data syncs to your network platform in real time.
Key Features
Full Data Collection and Network Sync
Each parking event gets captured. It is synced to the central platform on its own, with no one stepping in. License plate data is archived by the controller. That supports reverse car-finding. Drivers can then locate their vehicles in large multi-level facilities.
Wireless Deployment
Installation gets simpler with wireless deployment. Less cabling to run means less work on site. That counts for a lot in big retrofits, or in new builds where extra cable infrastructure costs too much or just is not practical.
Offline Standalone Mode
Should the central server drop offline, the controller falls back to standalone mode. Camera data keeps coming in. Free spaces are still worked out. Local LED guidance screens keep updating too, so drivers see no break in service.
Stable RF Signal with Anti-Interference Design
Other electronic systems sit nearby, and the RF communication module is built to shrug off their interference. This holds in underground garages and enclosed parking structures. Signal conditions there can be tough, yet data transmission stays consistent.
Flexible Expansion
Your parking lot grows, and the modular architecture keeps up with it. Zones can be added later. You do not have to rip out what is already there, so future upgrades with a Video Parking Guidance Zone Controller cost less and get less complicated.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ZOJE-02ZV |
| Detector Capacity | 60 3-space video detectors in 5 roads |
| Network Interface | 8 x 10/100M RJ-45 Network ports |
| Power Supply | AC110-240V |
| Working Temperature | -30℃ to +70℃ |
| Storage Temperature | -40℃ to +85℃ |
| Housing Material | Cold steel paint |
| Dimensions | 400×260×90mm |
Quality Control
Before any unit ships, it goes through a set testing sequence.
72-Hour Burn-In Test: For this check, the controller runs nonstop at 60°C or above while handling full processing load. That way, early semiconductor or soldering failures show up before the unit leaves the facility.
Data Packet Loss Analysis: Professional network analyzers put the device through broadcast storm conditions. Every sensor port sends at the same moment. Packet loss must stay below 0.1%.
Surge Immunity Testing: The unit is tested to IEC 61000-4-5. Voltage surges of up to 6kV strike it. Sites with unstable power grids are a good fit for it.
Interface Durability: RJ45 and RS485 ports go through mating cycle tests. Contact resistance gets checked as well. Both checks show the ports keep conducting in damp underground sites, over a long working life.
Application Scenarios for Video Parking Guidance Zone Controller
International Airports and Transit Hubs
Large parking areas at airports get split into zones, and zone controllers manage them. One unit looks after a single camera cluster. It also refreshes the LED signs for that zone in real time. Peak load is no problem, because the unit does not wait on a central server to be available.
Multi-Level Shopping Mall Parking
Retail sites get busy at certain hours. Say the management center drops offline for maintenance during that rush. The Video Parking Guidance Zone Controller keeps working on its own. Sensor input comes in live, and the unit drives the green and red guidance lights and the aisle displays from it. Traffic stays organized on every level.
Mixed-Use Business Complexes
Some facilities park tenants and visitors in the same building. Here the controller ties into barrier gates and access control systems. LPR data is processed at the edge, which lets the unit run zone-based access logic. That includes underground areas where signals are shielded.

OEM/ODM and Customization
Hardware and software customization is available from ZOJE. It is based on what each project needs. Do you need a certain enclosure rating, a different port setup, or software integration? The engineering team works with you directly to set the right specification.
- Standard Lead Time: 5–7 days
- Customized Lead Time: 10–15 days
- Shipping: Sea freight and air freight are both options. DDU and DDP terms can be arranged

Frequently Asked Questions
Q: What happens if the controller loses its connection to the central server?
A: Offline Standalone Mode takes over right away. Camera data keeps coming in. Free spaces are still counted, and the local LED signs keep updating. Drivers get guided the usual way, even with the network down.
Q: How many parking spaces can one unit manage?
A: A single unit manages 32 to 64 video detectors. The actual number of parking spaces covered depends on the camera-to-space ratio of your facility layout.
Q: Does it support fiber optic cascading?
A: Yes. The unit supports fiber optic connectivity via its SFP module slot for uplinks exceeding 100 meters. A ring topology is recommended over a linear chain to provide RSTP-based network redundancy if a single node fails.
Q: What are the power requirements?
A: The device accepts 100–240V AC input. When acting as PoE power sourcing equipment for connected cameras, the total power supply should be rated between 150W and 300W depending on the number of cameras connected.
Q: Can the controller isolate the camera subnet from the facility network?
A: Yes. The camera subnet sits physically apart from the upper-level facility management network. Nobody outside can reach the cameras directly. That leaves the building with a better overall cybersecurity posture.
Q: Can I get after-sales support from ZOJE?
A: Yes. Every unit comes with a 2-year warranty. Technical support is available 24/7. ZOJE also gives guidance on installation and long-term maintenance.
Contact Us
Have a project requirement? Contact our team at info@zoje-tech.com and we will help you find the right Video Parking Guidance Zone Controller solution for your parking facility.
