Vehicle Loop Detector for Parking Management System
2. Auto-tuning for instant setup
3. ASB mode for precise vehicle detection.
4. Adjustable frequency to prevent interference.
5. Dual-relay outputs for flexible control.
6. LED indicators for real-time diagnostics.
7. Industrial-grade design for long-term durability.
8.Warranty: 2 years
- Face to Face Discussion
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Vehicle Loop Detector for Parking Management System — ZOJE-LD132
The Vehicle Loop Detector for Parking Management System comes from ZOJE. It is an industrial-grade inductive sensor. Commercial and logistics parking sites rely on it for steady vehicle detection. Hong Kong ZOJE Intelligent Technology Co., Ltd. has made it since 2012. The ZOJE-LD132 covers an inductance range of 20µH to 1000µH. Reaction time sits between 10ms and 50ms, and the claimed detection accuracy reaches 99.9%. Auto-tuning is built in, along with ASB mode, dual-relay outputs, and adjustable frequency channels. Those features answer the usual parking control requirements.
What Is a Vehicle Loop Detector and How Does It Work?
A vehicle loop detector is an inductive sensor set into the pavement. It picks out metal vehicles by reading changes in an electromagnetic field. Once a car's metal chassis moves into the loop's magnetic field, the inductance of the loop drops. That drop sends a signal to the parking management system.
Optical sensors work another way. Rain, fog, or snow does not touch this technology, so it holds up better outdoors. It takes on the main parking control problems directly. Barriers stay up instead of coming down on a car, tickets get dispensed with no attendant, unauthorized tailgating is blocked, and occupancy data gets collected.
Key Features of the ZOJE-LD132
Auto-Tuning for Instant Setup
Once it powers up, the detector sets itself up on its own. That cuts the time spent configuring it by hand on site.
ASB (Automatic Sensitivity Boost) Mode
Sensitivity goes up in ASB mode when the loop picks up high-bed vehicles, trucks, or trailers. This helps stop missed detections that come from vehicles with little metal touching the road.
Adjustable Frequency Channels
Operators can set entry and exit loops to different frequency bands — for example, High on entry and Low on exit — maintaining a separation of at least 15kHz to reduce crosstalk between adjacent loops.
Dual-Relay Outputs
There are two relay outputs, and each one works on its own. You can hook them up to barrier gates, traffic lights, counting systems, or alarm devices in the same installation.
LED Lights That Show Live Diagnostics
On-board LED indicators show loop status. Detection events and fault alerts show up too. A technician can find issues from these lights alone. No extra diagnostic equipment is needed.
Industrial-Grade Vehicle Loop Detector for Parking Management System Housing
The detector unit sits in a polyamide housing. That plastic is industrial grade. It mounts on a DIN rail. Long-term use in electrical cabinets is fine, including at parking facility entry and exit points.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ZOJE-LD132 |
| Supply Voltage | 230V AC, 115V AC, 24V DC/AC, 12V DC/AC |
| Power Consumption | 4.5VA |
| Output Relays | 240V/5A |
| Frequency Range | 20 kHz to 170 kHz |
| Reaction Time | 10ms |
| Operating Temperature | -20°C to +65°C |
| Loop Inductance | 50μH to 1000μH |
| Dimensions | 78 × 40 × 108 mm |
| Warranty | 2 years |
Application Scenarios
Commercial Parking: Shopping Malls and Airports
In Presence Mode, the detector is placed beneath the barrier arm as an anti-crush safety device. A secondary loop in Pulse Mode activates ticket dispensing only when a vehicle is confirmed present.
Smart City parking guidance systems
Two tracking loops, Loop A and Loop B, sit close to each other. Together they work out which way a vehicle is going. That data goes into a Parking Guidance System (PGS), which then shows the live count of free slots on the signage displays.
Industrial Freight and Logistics Parks
Nearby machinery can create high EMI. In that kind of setting, the frequency filtering in the detector helps it keep detection accuracy. Vehicle access in secure zones can be managed too, by controlling interlocking doors and weigh-in-motion stations.

Quality Control Standards for Vehicle Loop Detector for Parking Management System
Each ZOJE-LD132 unit goes through a defined inspection process before shipment.
- Insulation Resistance Testing: Loop wire is tested at above 100 MΩ to check for ground leakage, a common cause of loop malfunction.
- Surge and Lightning Protection: Gas discharge tubes or VDRs are incorporated to handle voltage spikes in outdoor environments, in line with IEC 61000-4-5.
- Frequency Stability Testing: Testers run the oscillator frequency through temperature cycling (-40°C to +85°C). Drift must stay at or below ±5%.
- Crosstalk Immunity Verification: Several detectors run side by side in adjacent lanes at the same time. Each one sits on a different frequency channel. The goal is to prove mutual interference stays inside acceptable limits.
That framework governs the Vehicle Loop Detector for Parking Management System manufacturing process.
Why Choose ZOJE?
- Delivery: Standard units leave our warehouse in 5–7 business days. Customized configurations take 10–15 business days.
- OEM/ODM Support: Need something specific for your project? We customize both hardware and software.
- 2-Year Warranty with global technical support
- Flexible Shipping: Goods can go by sea or by air. We work with both DDU and DDP trade terms.
- Engineering Team: In-house electronic and mechanical engineering resources with documented design patents

Frequently Asked Questions
Q: What makes the parking barrier stay up after the car drives away?
A: This is typically a loop latching issue caused by a sudden inductance change — often from a loose wire in the pavement slot or degraded sealant. Recalibrating the detector and checking sealant integrity usually resolves it.
Q: Can this vehicle loop detector detect carbon fiber or composite vehicles?
A: Loop detectors rely on conductive metal mass to change inductance. Most vehicles carry sufficient metal in the engine block and chassis. For fully composite vehicles, higher sensitivity settings or auxiliary radar sensors are recommended.
Q: How can the entry and exit loops avoid interfering with each other?
A: Give the entry loop a High frequency band. The exit loop should take a Low frequency band. Keep the channels at least 15kHz apart.
Q: What is the correct slot depth for loop wire installation?
A: Most installers cut the slot 30mm to 50mm deep. Once the wire sits in place, fill the slot with epoxy or bitumen-based loop sealant. That keeps the loop from shifting and stops water from getting in.
Q: Can the system be used on pavement that has steel mesh inside it?
A: Yes. Steel rebar pulls the loop's Q-factor down. Mount the detector at least 50mm above the mesh. Then set the sensitivity higher to make up for the damped signal.
Q: Can ZOJE build custom setups for parking systems that have several lanes?
A: Yes. ZOJE supports OEM and ODM configurations for multi-lane deployments, including software integration and hardware layout adjustments based on project requirements.
Contact Us
Have a question about the ZOJE-LD132 or need a custom configuration? Reach our Vehicle Loop Detector for Parking Management System team at info@zoje-tech.com.
