Automatic Pay Kiosk for Commercial Parking Projects

Automatic Pay Kiosk for Commercial Parking Projects

1.OS: Android 4.0 above
2.Coins receiver and change machine(cycle) : customized
3.Notes receiver and change machine (cycle): customized
4.Receipt printer
5.Payment methods: Cash, QR code, credit card
6.Alarm when has external force open machine
7.CCTV monitoring optional
8.Support OEM and ODM
  • Face to Face Discussion
  • Quality Assurance
  • 24/7 Customer Service

Product Introduction

Automatic Pay Kiosk for Commercial Parking Projects — Self-Service Payment Solution for High-Volume Parking Facilities

A self-service payment terminal, that is what this Automatic Pay Kiosk for Commercial Parking Projects is. The trade calls it Pay-on-Foot (POF). Busy gated parking sites are where it fits. Hong Kong ZOJE Intelligent Technology Co., Ltd. built the unit. Shenzhen is where the company started, back in 2012. Cash works. QR codes work too, and so do credit cards. Inside the machine, coins and notes get recycled. Receipts come out on the spot. Optional CCTV monitoring can be added. No member of staff has to stand and watch it. The kiosk keeps working day and night. Fewer people on site is what commercial parking operators then need.

What Is a Pay-on-Foot Parking Kiosk?

Drivers pay at the kiosk, before they walk back to the car. At the exit gate, nothing gets paid. Exit queues are the usual reason commercial parking facilities jam up. This setup takes them away.

No one waits in a line of cars behind a barrier. Payment is made in the lobby, or in the transition zone. Once the payment is confirmed, the exit gate lifts. On-site staff numbers drop, and cash becomes easier to control. The kiosk runs on its own around the clock.

Key Features and Technical Properties

The kiosk cabinet is built from cold-rolled steel or stainless steel. Powder coating gives it the finish. Enclosure ratings come in at IP54 or IP65. Indoor lobbies are a good fit. The same unit also holds up in covered parking that is semi-outdoor.

The screen is a touchscreen. Brightness sits at 1,000+ nits, and sizes run from 15 to 19 inches. Reading stays easy even when the light around it is strong. An industrial-grade PC handles the processing. Smart heaters and fans let the unit run from -40°C to +75°C.

Inside the cash handling module, coins and notes are both recycled. Change comes out of the cash that went in. Fewer cash collection visits follow from that closed loop. The card reader holds EMV Level 1 and Level 2 certification, and it meets PCI-DSS standards. Ticketless entry goes through the built-in QR code scanner. The same scanner validates coupons from tenants or partner businesses.

If someone forces the cabinet open, an alarm triggers on its own. The parts are modular too. Single components can be swapped one at a time. That keeps downtime short at busy sites.

Technical Specifications

Component Specification
Display 17-inch touch screen
Operating System Android 4.0 and above
IC Reader 13.56MHz frequency
Coin Management Customized receiver and recycling system
Bill Management Customized receiver and recycling system
Receipt Printer Built-in thermal printer
Ticket Scanner Barcode/QR code reader (optional)
Cooling System Four internal fans with temperature control
Interior Lighting LED system with automatic door detection
Security Features Force detection alarm system
Computing Power Built-in industrial-grade mini PC
Surveillance CCTV monitoring (optional)
Customization Full OEM/ODM support available

Application Scenarios

Mixed-Use Retail and Office Complexes

Validation logic is usually needed at sites like these. A retail purchase or an event ticket may come with a set free period, for instance. The kiosk scans barcodes, paper or digital. Then it works the fee out again. Exit lanes keep moving during peak egress periods.

Airports and Automatic Pay Kiosk for Commercial Parking Projects Transit Hubs

Uptime in these environments has to stay steady. Long-term parking sums are worked out by the kiosk, and pre-booking QR codes get read there too. An IP65 enclosure is part of the build, along with a wide operating temperature range. Vehicle exhaust builds up in such places. Humidity runs high. Temperatures swing a lot. The unit keeps working through all of it.

Hospital and Healthcare Campuses

ADA height standards can be met by configuring the kiosk. Voice guidance comes built in. So does a simple interface that works for patients and visitors. Frequent-visitor passes are supported too. So are multi-day parking arrangements, all run from a central system.

application

Quality Control Process for Automatic Pay Kiosk for Commercial Parking Projects

Before any unit ships, it goes through structured testing.

In Environmental Stress Screening, units go into climatic chambers. Temperatures inside swing to extremes. Humidity climbs to 95%. This is how screen readability gets checked. The internal PC is checked too. It must run within normal parameters in these demanding conditions.

Wear shows up early when parts are cycled hard. Peripheral Cycle Testing puts the bill validator and receipt printer through long accept/reject and cut runs, so weak spots get found before the unit goes live.

Calibrated water jets and dust chambers do the work in IP Rating Verification. The goal is proof that the enclosure still holds its rated IP54 or IP65 level before it heads outdoors.

EMV Level 1 and Level 2 compliance gets checked under Electronic Payment Security Audits. Auditors also look at the anti-skimming bezel to see if it is intact. That tells you whether each unit is ready for PCI-DSS.

certification

Customization and OEM/ODM Services

Both hardware and software can be customized to fit a project's needs. ZOJE takes care of that. Options include custom cabinet design and branded interfaces. Specific payment methods can be integrated too. For individual sites, fee logic can also be changed.

System integrators and parking operators who buy equipment at scale can work with us on Automatic Pay Kiosk for Commercial Parking Projects through OEM or ODM partnerships. The main logistics details are below:

  • Standard products: ship within 5–7 days
  • Customized units: typically ready in 10–15 days
  • Shipping options: sea or air freight, under DDU or DDP terms

Frequently Asked Questions

Q: What if the network connection goes down?

A: The link can fail. The kiosk keeps running offline. Every transaction goes into a SQLite database stored on the unit itself. When the connection comes back, those records sync to the central server on their own. No data gets lost.

Q: Does the kiosk work with ANPR cameras already in place?

A: Yes. An Open API or SDK integration layer can pull plate numbers from ANPR systems into the kiosk. At that point no ticket is needed to pay. The plate number itself works as the entry credential.

Q: How regularly must the cash system be serviced?

A: Transaction volume decides how often the system needs service. Cash the machine has already collected is used to pay out change, because the recycling mechanism puts that money back to work. That means fewer Cash-in-Transit visits. Cassettes that hold more stretch the service intervals even further.

Q: Could a person tamper with the kiosk or vandalize it?

A: The cabinet stays shut with locks at several points. Drilling through them is not easy. Parts sit on shock mounts inside. If somebody tries to force the cabinet open, a vibration sensor sends out a silent alarm.

Q: How do tenant validation discounts get applied?

A: Tenants hand out validation coupons. They can be printed or digital. The multi-spectrum barcode scanner built into the unit reads them. Balance due gets recalculated by the fee logic on the spot. Nothing has to be typed in by drivers.

Q: What certifications does the payment system have?

A: EMV Level 1 and Level 2 certification is held by the card reader. Protection of financial data also meets PCI-DSS standards. Quality management at the plant runs to ISO 9001:2015 requirements.
