Front-Mounted Ultrasonic Parking Space Detector

Front-Mounted Ultrasonic Parking Space Detector

1.Model:ZOJE-02F
2. All-in-one compact detector design
3.Fits every single parking slot
4. High-precision detection.Collects parking data instantly
5.Red-green light alert . Signals space full/empty clearly
6.Plug-and-play setup . No complex wiring required
7.Indoor-outdoor compatible .Suits all parking lot scenarios
8.24/7 tech support and service
  • Face to Face Discussion
  • Quality Assurance
  • 24/7 Customer Service

Product Introduction

Front-Mounted Ultrasonic Parking Space Detector – ZOJE-02F All-in-One Parking Guidance Solution

The Front-Mounted Ultrasonic Parking Space Detector ZOJE-02F handles two jobs in one small housing. It detects a vehicle right away. It also has RGB LED lights built in. The unit runs on 40kHz ultrasonic time-of-flight (ToF) technology. It finds a vehicle with an error margin under 0.1m. RS485 (Modbus) handles communication, and the signal can travel up to 1,000m. Red means the space is occupied. Green means it is free. You can see the light from more than 50 meters down an aisle.

What Is the ZOJE-02F and How Does It Work?

Old split-type parking detectors keep the sensor and the indicator light apart. That setup needs extra cable runs and more steps at install time. The ZOJE-02F puts both parts into one unit. You mount it right above the front edge of a parking space, usually on a raceway or an overhead bridge.

The sensor sends out 40kHz ultrasonic pulses. It measures how long the echo takes to return. That tells the unit if a vehicle is there. If the space is occupied, the LED turns Red. A free space shows Green. This simple logic makes checks and troubleshooting faster on site.

With the single-unit design, each space needs fewer cable terminations. Split systems need more. Installation gets simpler in facilities with many spaces.

Key Features

Integrated All-in-One Design

One unit handles both detection and visual indication. No separate wire run goes from a sensor head to a remote light. That keeps overhead cable management cleaner. It also cuts the number of connection points that could fail over time.

Multi-Color RGB LED Indication

Red and Green are not the only colors. The built-in RGB LEDs also support Blue (Disabled), Pink (Ladies-Only), White (VIP), and Cyan. Your central management software can change colors in real time via RS485 commands. No hardware changes or on-site visits are needed.

Anti-Interference Debounce Filter

A space only flips to Occupied once something has been sitting there for 3–5 seconds without a break. A pedestrian walking through, or a cart pushed past, won't set it off. That is how the firmware filters out false readings.

Standalone Mode

Say the link to the zone controller drops. Sensing goes on regardless. The detector still flips its own LED between Red and Green right there on the unit. So drivers keep getting visual guidance while the backend is offline.

Wide Installation Height Range

Mount the sensor somewhere between 2.0m and 3.5m for best results. Ceilings taller than 4.0m? Suspender rods bring the Front-Mounted Ultrasonic Parking Space Detector unit down into the effective range. Detection distance can be set anywhere from 0.5m to 4.5m through software configuration.

Technical Specifications

Parameter Specification
Model ZOJE-02F
Detection Accuracy ≥99.9%
Response Time <2s after vehicle stops
Indicator Light 7 color high brightness LED
Communication RS485
Communication Distance ≤300m (CAT5e)
Ethernet Ports 2×RJ45 interface
Operating Voltage DC 10~28V (Rated 24V)
Power Consumption <2W
Dimensions Ø126×125mm
Housing Material Gray ABS engineering plastics

Application Scenarios

Large-Scale Shopping Centers

Some sites hold hundreds of parking spaces. The built-in LED can be seen from more than 50 meters down an aisle. That helps drivers find open spaces instead of circling. During busy periods, a 3–5 second debounce filter stops the system from reading pedestrian movement as a change in occupancy.

Corporate and Office Complexes

RGB support lets the central management system pick a color for each space. White can mark VIP, Blue can mark reserved. Nothing on site needs a hardware change. Colors can also be updated remotely through an RS485 command.

Airports and Railway Stations

Traffic rarely stops in these places. Vehicle exhaust and mechanical vibration are part of daily life there. With its IP40–IP54 rating and -20°C to +65°C operating range, the ZOJE-02F suits covered garages and semi-exposed transit facilities. Zone controllers and Variable Message Signs (VMS) link to the device, which then points travelers toward zones that still have room.

Quality Control Process for Front-Mounted Ultrasonic Parking Space Detector

Before any ZOJE-02F unit ships, it goes through a set inspection process:

  • Detection Accuracy and Blind Zone Test: A test object gets moved through the detection cone. This checks the trigger thresholds. The blind zone must measure under 0.3m.
  • Burn-In Test: Each unit runs non-stop, with the LED toggling and the ultrasonic pinging on. Any part that fails early shows up here, before the unit leaves the line.
  • Temperature Cycling Test: Each unit goes through the full working range, from -20°C to +65°C. This confirms the ultrasonic transducer keeps a steady frequency as temperature changes.
  • Voltage Fluctuation Test: This test checks that the unit still works when the power supply moves up and down. Those swings match what happens in large facilities.
  • RS485 Communication Test: At high polling frequencies, we check the communication link. The aim is stable data exchange between the detector and the zone controller.

Customization and OEM/ODM

Hardware and software customization is available from ZOJE, and it is built around what each project needs. You can pick specific LED color schemes. Housing color can be changed too. Communication protocol adjustments are possible, and we also support software integration.

Standard products go out in 5–7 business days. Customized orders usually ship in 10–15 business days. Sea freight and air freight are both offered. DDU and DDP trade terms are supported.

Got a customization requirement to talk through? Reach the team about the Front-Mounted Ultrasonic Parking Space Detector at info@zoje-tech.com.

Front-Mounted Ultrasonic Parking Space Detector

Front-Mounted Ultrasonic Parking Space Detector

Frequently Asked Questions

Q: What keeps the detector from picking up reflections off cars in nearby spaces?

A: Detection is aimed downward at the space right under the unit, and the ultrasonic beam angle sits between 15° and 30° to make that happen. Each detector has its own address in the Modbus polling setup. So the system reads each unit's response on its own. Nothing gets broadcast across the bus at the same time.

Q: Is it possible to change the LED color without swapping out any hardware?

A: Yes. The indicator talks over RS485. That means your central management software can send a command to switch the LED color. Say you want Blue for a reserved space instead of Green. No one has to touch the unit to do it.

Q: What if the network connection drops?

A: Standalone Mode is built into the ZOJE-02F. Lose the link to the zone controller and the device keeps detecting vehicles. Its LED still switches between Red and Green from local sensing. Drivers still get visual guidance.

Q: How does the detector tell a parked car apart from someone walking past?

A: The firmware runs a debounce filter. A space only gets marked Occupied after detection stays continuous for 3–5 seconds. Someone walking through the zone never stays still long enough to flip the status.

Q: What height should the unit be installed at?

A: Mount it between 2.0m and 3.5m above the parking surface. That range works best. If the ceiling sits higher than 4.0m, add suspender rods so the sensor hangs closer to the target zone.

Q: Can This product handle outdoor parking areas?

A: The ZOJE-02F carries an IP40–IP54 rating and runs from -20°C to +65°C. Covered indoor facilities suit it, and so do semi-exposed outdoor parking environments. Sites that sit fully in the open and take direct rain need a check first. Confirm the IP rating your site calls for before you specify the unit.
