Indoor Parking Guidance Central Controller
2.System core hub.
3.Real-time data collection,screen update
4.Guidance screen update.Enables accurate vehicle navigation
5.Fits complex indoor garage scenarios
6.Wireless deployment. Labor cost saving
7.High-stability operation .Anti-interference
8.24/7 tech support and service
- Face to Face Discussion
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Indoor Parking Guidance Central Controller – System Core Hub for Smart Parking Solutions
Data processing for an indoor parking guidance system runs through the Indoor Parking Guidance Central Controller (Model: ZOJE-02M). It comes from Hong Kong ZOJE Intelligent Technology Co., Ltd. Since 2012 this maker has been active, and it holds ISO 9001:2015 certification. Live sensor data comes in. The ZOJE-02M takes that feed and updates the guidance screens at once. One deployment can handle up to 25 zone/node controllers. Multi-level garages get round-the-clock service from it. Cabling work on site drops when you go wireless.
What Is a Parking Guidance Central Controller?
In the middle sits the controller. One side takes input from parking sensors. The other side connects zone controllers and the management server. Occupancy data flows in and is processed. Routing logic gets worked out in the same place. Space availability then goes out to each guidance display, live.
Take away a dependable controller at the center and the screens start showing stale data. Drivers circle for no reason. Congestion builds up in the facility and users end up with a poor experience.
The ZOJE-02M addresses this by keeping all data synchronized — even when the server goes offline.
Product Specifications
| Parameter | Specification |
|---|---|
| Model | ZOJE-02M |
| Communication Mode | Ethernet, CAN |
| Communication Distance | CAN: ≤1000m |
| Communication Objects | CAN: indoor node/zone controllers; Ethernet: system management platform |
| Operating Voltage | AC 110~240V |
| Power Consumption | ≤2W (excluding detector power) |
| Dimensions | 320×260×90mm |
| Housing Material | Galvanized steel plate with spray coating |
Key Features
Live Data Capture and Screen Refresh
Occupancy status reaches the ZOJE-02M from parking sensors all the time. The guidance screens receive updated space counts. At each decision point, drivers see correct information. So they spend less time hunting for a bay.
Offline Edge Computing
Suppose the network or the server fails. Even then, the controller keeps working through sensor data on its own, using zonal logic that was configured in advance. Guidance displays stay current. In large facilities this matters a lot. There, vehicle flow depends directly on whether the system stays available.
Wireless Deployment Support
Wireless deployment is one of the options the system offers. That cuts down on cabling work at the site. For big garages, or ones with a complex structure, labor costs drop and installation takes less time.
Handles a Wide Temperature Range and Resists Interference
The ZOJE-02M runs from -20°C to +70°C. Cold winters, hot summers, and electromagnetic interference from vehicle electronics are all part of life inside a parking structure, and the unit is built for them. Its industrial-grade metal chassis holds IP40/IP54 protection ratings.
Remote Firmware Upgrades
Firmware updates can be sent in by a Indoor Parking Guidance Central Controller from a distance. Nobody needs to go out to the site. That cuts the upkeep work over the years.
Quality Control
Every ZOJE-02M unit goes through a multi-stage quality process before shipping.
72-Hour Burn-In Test
Each unit runs flat out for 72 hours without a break. Hardware that fails early shows up in that run. The faults get caught before the product leaves the factory.
Data Packet Loss Rate Testing
During simulated high-traffic data conditions with concurrent sensor status changes, the packet loss rate must stay below 0.1%, keeping guidance data accurate during peak parking hours.
ESD and Surge Protection Testing
Every interface is tested for electrostatic discharge up to ±4kV (contact) and ±8kV (air). Surge immunity testing covers the power and Ethernet ports. That way they handle the voltage spikes you see in parking garage electrical environments.
Thermal Stress Screening
Thermal chambers cycle the unit from -20°C to +70°C. That run puts the ARM processor and the capacitors to the test. Both have to behave the same way in every operating condition.

Application Scenarios for the Indoor Parking Guidance Central Controller
The Indoor Parking Guidance Central Controller is designed for demanding B2B and B2G parking environments.
Large Shopping Complexes
Sites with several levels often have more than one parking zone. The controller there handles separate areas: standard parking, EV charging, and disabled parking. Routing logic spans the floors. Wayfinding signs are kept up to date too. Congestion on the ramps builds up less that way.
Airports and Transport Hubs
Vehicles arrive and leave all day long. That means the system can't afford any downtime. The controller keeps working on its own, so a network outage does not take it out. Screens never freeze on stale data. Guidance keeps showing correct information.
Mixed-Use Commercial Buildings
Some facilities take both contract parkers and transient visitors. In those sites, the controller can connect to Parking Management Systems (PMS). That link lets it handle zone allocation dynamically.

OEM/ODM and Customization
ZOJE offers hardware and software customization for the central controller. This covers protocol adaptation for third-party LED screens. It also covers integration with existing PMS platforms. For projects that need branded or application-specific configurations, OEM and ODM cooperation is available.
Want to talk over project timelines and trade terms for your requirements? Contact our team.
FAQ
Q: What happens to the guidance system when the server goes down?
A: Local processing and edge storage come built into This product. Sensor data keeps arriving as it always does. Screens keep refreshing from the zonal logic that was set up ahead of time. So the facility stays up and running while the server is down.
Q: How many detectors can one central controller take at most?
A: One ZOJE-02M handles 25 zone or node controllers. Spread across up to 4 bus loops, that grows to roughly 960 single parking sensors. Signal quality holds up at that size.
Q: Which cables do I need for communication?
A: CAT5e or CAT6 cable carries the TCP/IP link to a switch or server. For field sensors on RS-485 or CAN Bus, use RVSP 2×1.0 twisted pair. Something equivalent works too.
Q: Do third-party LED screens work with this controller?
A: Yes, if the screen speaks a standard protocol. Modbus TCP and plain TCP/IP both work. While you procure, confirm the screen is compatible. Some proprietary protocols need extra setup work.
Q: Garages often have unstable voltage. How does the device handle that?
A: On the ZOJE-02M the DC input goes from 12V to 24V, so the range is wide. Self-recovery fuses come built in. If the site is critical, you can also pair the unit with an external UPS.
Q: What warranty does ZOJE provide?
A: Every unit comes with a 2-year warranty. Want the details on technical support and maintenance? Just reach out to our team.
