ANPR for charge Parking lots

ANPR for charge Parking lots

1. Model:B0X-A30-IV
2. Operating system:LINUX
3. Parking system architecture:B/SArchitecture
4. Operating Temperature:-35℃- 70℃
5. Working power supply: external power adapter enter:AC 110V-220V,Output:DC 19V/12V
6. Multi-language support
7. Suitable for various scenarios
8. High stability-The system is stable and can be guaranteed5No downtime for a year
9. Various charging methods-Flexible response to various management needs, such as temporary vehicles, fixed users, special users, etc
  • Face to Face Discussion
  • Quality Assurance
  • 24/7 Customer Service

Product Introduction

ANPR for Charge Parking Lots: Ticketless Billing System for Paid Parking Facilities

Money leaks out of paid parking every day. Ticket machines jam. Cars queue at the exit and wait. ANPR for charge parking lots takes aim at all three problems. ZOJE Intelligent Technology Co., Ltd. builds the BOX-A30-IV, which runs on a LINUX-based B/S architecture. Multi-language interfaces come as standard, and the unit handles flexible charging modes for temporary visitors, fixed users, and special accounts. Operators who want billing that runs itself and holds up in daily use will find it a practical choice.

What Is This Product?

In paid parking facilities, revenue management software can be wired straight to Automatic Number Plate Recognition. That setup is what this product means: a billing system built for one job, done automatically.

A high-resolution camera grabs the plate image as the vehicle pulls in. Optical Character Recognition (OCR) turns that image into alphanumeric data. Next, the system checks the result against payment databases. Parking duration gets calculated from it, tariff rules get applied, or a pre-booking gets validated.

No physical ticket dispenser is part of this process. Paper tickets are gone. Mechanical parts that can fail are gone as well. Revenue loss from ticket swapping or tailgating is removed too.

Key Technical Specifications

Parameter Specification
Model B0X-A30-IV
Dimensions 130mm × 175mm × 55mm
Color Black
Operating System LINUX
Architecture B/S Architecture
Temperature Range -35℃ to 70℃
Power Supply External adapter AC 110V-220V, Output DC 19V/12V
Heat Dissipation All-aluminum alloy fanless design
Minimum Capacity 3 Entry + 3 Exit lanes
Maximum Capacity 10 Entry + 10 Exit lanes

Core Features and Technical Advantages

The BOX-A30-IV comes with a Global Shutter image sensor. It is rated between 2MP and 4MP. Vehicles moving at speeds up to 40–60 km/h are captured without motion blur. Built-in infrared (IR) illuminators keep OCR accuracy above 99% in low light and total darkness. They do not cause light pollution in nearby areas.

OCR processing runs on the device. No remote server is involved. This local processing keeps the barrier trigger signal under 200ms. That helps prevent traffic jams at busy entry and exit lanes.

Offline Mode is built into the system too. Should the link to the cloud payment server drop, the hardware keeps entry and exit logs on an SD card or internal SSD. Data syncs by itself once the connection is back, and no billing record goes missing.

The housing is rated IP66 or IP67. That keeps rain, dust, and vibration away from the parts inside. Working temperatures run from -35°C to +70°C, which covers outdoor surface lots in cold climates and heated underground garages alike.

Application Scenarios

Retail and Shopping Centers

At busy retail sites, cars drive in without stopping for a ticket. The camera records the plate on the way in. Payment happens by app or kiosk when the driver leaves. Before the barrier lifts, the camera checks that transaction in real time, so queues stay shorter at peak hours.

Airports and ANPR for charge Parking lots Transport Hubs

Billing at airports gets complicated. There are short-stay drop-off zones, long-term lots, and valet areas. Each zone has its own rates, and the system notes which one a vehicle enters, then works out the fee from that zone's price. It also spots a vehicle that leaves and comes straight back in to restart the billing clock. That helps operators deal with tariff evasion.

Unmanned Commercial Parks

Some open lots run with no staff on site. There, ANPR cameras do the enforcement job. Actual stay length gets compared with the digital permit that was bought. A vehicle that overstays, or never paid, can set off a workflow that issues a Parking Charge Notice (PCN) on its own.

application

Quality and Performance Testing for ANPR for charge Parking lots

Recognition performance directly affects billing coverage. Before shipping, the BOX-A30-IV undergoes testing across several conditions.

Camera capture rates are verified under varied lighting — direct sunlight, low-light underground environments, rain, and fog — to confirm stable performance across real-world conditions.

Barrier trigger latency is measured to confirm the time between image capture and gate signal stays within the 200ms specification.

Dirty plates get tested against the OCR engine. So do damaged ones and plates that do not reflect light well. Calibration follows the plate font standards of each region.

We also run tests where the network drops. The goal is to confirm the system keeps transactions on the device while the outage lasts. Once the link is back, those records have to upload correctly.

certification

Data Privacy Considerations

The system supports AES-256 encryption for stored vehicle records. Privacy masking options allow operators to blur driver faces and surrounding imagery in saved frames. Configurable auto-deletion policies enable operators to retain vehicle data only for the period required for billing and enforcement purposes — features designed to support compliance with applicable data privacy regulations.

Customization and OEM/ODM Services

ZOJE supports hardware and software customization for parking system projects. Integration with existing Parking Management Systems (PMS), custom payment gateway connections, and localized interface languages can be configured to match your project specifications.

OEM and ODM cooperation is available. Talk to the team about ANPR for charge Parking lots and what your project needs and how delivery would work.

Frequently Asked Questions

Q: How does recognition accuracy affect revenue in charge parking lots?

A: Higher accuracy means the system captures more billing events on its own. On tough plates, dirty, damaged, or partly covered ones included, the BOX-A30-IV aims for accuracy above 99%.

Q: Can the system work at night, or in underground garages where the lighting is poor?

A: Yes. Built-in IR LEDs and Wide Dynamic Range (WDR) sensors let the camera grab clear plate images when light is low or there is none at all. Ambient light levels play no part in image quality.

Q: What happens if the internet connection to the cloud payment server fails?

A: Offline Mode starts on its own. Logs for entries and exits stay on an SD card or the internal SSD. When the link returns, those logs sync back to the server.

Q: What happens with foreign or non-standard license plates?

A: The OCR engine learned from plate data sets from many countries. It uses syntax rules to work out which country a plate comes from. Then it changes the reading algorithm to fit that region's format.

Q: Does the system treat the vehicle data it gathers with privacy in mind?

A: AES-256 encryption is built in. Driver faces can be masked. Auto-deletion policies can be set too. With these tools, operators can meet their data privacy duties.

Q: Which charging modes can the system handle?

A: The system handles temporary vehicle billing, fixed user accounts, and special user categories, covering the range of management needs for commercial parking facilities.

Contact Us

Reach our team at info@zoje-tech.com to discuss your ANPR for charge parking lots project requirements.
