24/7 unattened LPR parking operations
2.Recognition rate:99%
3.Recognition Regions:Around world
4.Support offline use:Front-end recognition, unaffected by network delay/offline. Support offline billing
5.Support hardware/software customized,support various types of secondary development
6.Support outdoor use
7.24/7 service
8.Support OEM and ODM
- Face to Face Discussion
- Quality Assurance
- 24/7 Customer Service
Product Introduction
ZOJE-LPR101 Automated LPR Parking System Enables 24/7 unattened LPR parking operations
Hong Kong ZOJE Intelligent Technology Co., Ltd. built the ZOJE-LPR101 for operators who need 24/7 unattended LPR parking operations. These operators do not want permanent on-site staff. Plate reading runs at the camera edge. The system controls barrier gates. It logs each transaction. Billing is supported too. The system can run 24/7 unattened LPR parking operations offline when needed. License plate formats from around the world are recognized. The stated recognition rate is 99%. Hardware customization is offered. Integrators and resellers can work through OEM cooperation. ODM cooperation is open too.
How Unattended LPR Parking Works
Older parking management leans on staff. Paper tickets are common. So are RFID cards. Every one of these methods raises running costs. Each also adds a place where things can go wrong.
As soon as a car pulls into a lane, an LPR-based system reads its plate. The camera spots the plate. It checks that plate against a local whitelist. Next, it raises the barrier gate. A record of the transaction is saved. No operator needs to be there. When the car leaves, the same steps apply. Its plate gets read one more time. The system works out the fee. Then the gate opens. Depending on your setup, payment can go through integrated methods.
What does that mean in practice? Cars roll through the entry and exit lanes non-stop, day and night. No staff needed at the lanes.
ZOJE-LPR101 Key Features
Front-End Edge Recognition
Image processing happens right on the camera chipset. Even with no internet, the barrier gate still opens. Offline billing keeps each transaction record intact. Once the connection comes back, data syncs on its own.
99% Recognition Rate
ZOJE-LPR101 posts a stated 99% recognition rate on plate formats from around the world. That covers plates that are dirty, angled, or non-standard. Capture takes under 200 milliseconds, so cars queue less at the lane.
Outdoor-Ready Construction
The housing is made for outdoor use. Its anti-corrosion materials hold up in coastal areas and in places with heavy pollution. WDR imaging copes with tricky light, from direct headlight glare to dim night scenes.
Wide Protocol Compatibility
Wiegand, TCP/IP, and RS485 protocols all work on this system. That means it can tie into most barrier gates and access control setups already on site.
Secondary Entry Fallback
When OCR confidence is below threshold, the system can fall back to QR code or credit card entry, so a vehicle is not left waiting at the gate. Remote support alerts can also be triggered at this point.
Typical Deployment Environments
The ZOJE-LPR101 is designed for sites that require high vehicle throughput and controlled access for 24/7 unattened LPR parking operations without permanent on-site personnel.
Mixed-Use Commercial Complexes
Monthly permit holders get one class. Validated shoppers with discount logic get another. Transient visitors fall into a third, and the system tells them apart. Validation rules run on their own at the exit lane.
Airports and Rail Stations
Every entry and exit timestamp is logged with precision. From that data the system enforces free dwell-time windows. Cars that overstay get billed automatically.
Gated Residential Communities
Residents on the register drive through on plate recognition. Guest plates registered ahead of time can receive temporary access. This happens through the 24/7 unattended LPR parking operations platform, so no guard is needed at the gate.
Office Parks and Hospitals
Lanes keep moving at peak hours. The same holds during scheduled maintenance windows. Capture takes under 200ms, and billing carries on offline.
Technical Specifications for 24/7 unattened LPR parking operations
| Parameter Category | Specification |
|---|---|
| Operating Voltage | AC110-240V±10% |
| Operating Temperature | -20℃ to +60℃ |
| Relative Humidity | ≤95% without condensation |
| Rated Power | ≤60W |
| Communication | TCP/IP, RS485 |
| Protection Class | IP64 |
| Dimensions | 3601501490mm |
| CPU | Dual-core 900MHz + CNN acceleration |
| Image Sensor | 1/2.8" starlight-level CMOS |
| Max Resolution | 1920×1080 |
| Recognition Rate | ≥99% |
| Network Interface | 10/100Mbps adaptive RJ45 |
| Storage | TF card slot (max 512G) |
Quality Verification Process
Before any ZOJE-LPR101 unit ships, it has to pass performance verification.
Angular Tolerance Testing shows the unit still reads plates correctly at horizontal and vertical angles up to 45 degrees. That matters on entry ramps that curve or sit at an angle.
Environmental Stress Testing puts OCR accuracy to the test. A confidence score above 95% has to hold up in simulated heavy rain and snow. The same goes for low-light conditions below 0.1 lux, with infrared illuminators doing the work.
Latency Verification measures one gap: the time from image capture to the barrier open command. Under load, that delay must stay below 1.5 seconds.
Failover Protocol Inspection looks at what happens after an outage. Local storage must keep the transaction logs and sync them back. Parking records stay intact that way.
ISO 9001:2015 certification is in place at ZOJE. Patents cover the company's whole parking system product line, including 24/7 unattened LPR parking operations, too.
Customization and OEM/ODM
Your project may need more than a standard setup can give. In that case ZOJE builds the hardware and software to your own specifications, and full customization is on offer.
Operators, resellers, and system integrators who deploy under their own brand can work with ZOJE through OEM or ODM cooperation. Design work spans electronic and mechanical engineering. Changes at either level stay in-house.
Standard configurations ship in 5–7 days. Customized units ship within 10–15 days.
| Component | Specification |
|---|---|
| LED Count | 10 pieces |
| Maximum Power | 10W |
| Control Method | Intelligent light sensitivity |
| Illumination Range | >50LUX at 5 meters |
| Angle Adjustment | Supported |

Frequently Asked Questions
Q: What happens when the internet goes down?
A: Whitelists and transaction logs sit right on the device, stored locally by the ZOJE-LPR101 through edge computing. Cars can still get in and out while offline. Once the connection comes back, everything syncs on its own.
Q: How does the system handle dirty or damaged plates?
A: Fuzzy matching logic is what the system uses. Vehicle color and model data get captured too, as secondary identifiers. Say the OCR confidence score drops under threshold. Then a remote support alert goes out, or the system falls back to QR code or credit card entry.
Q: Can the system prevent tailgating?
A: The system ties into inductive loop detectors and anti-passback logic. That lets it spot a second vehicle trying to exit on a single open cycle. The transaction then gets flagged for review.
Q: How is plate data handled from a privacy standpoint?
A: Data handling practices depend on the operator's configuration and local regulatory requirements. The platform supports license plate hashing and configurable data retention schedules. Operators deploying in GDPR-applicable regions are responsible for ensuring their configuration meets applicable obligations.
Q: Does ZOJE support secondary development and third-party integration?
A: Yes. The ZOJE-LPR101 supports API and SDK-based secondary development. Protocol compatibility with Wiegand, TCP/IP, and RS485 allows direct integration with most third-party barrier and access control systems.
Contact Us
To request product specifications, discuss OEM cooperation, or get 24/7 unattened LPR parking operations configuration guidance for your site, email us at info@zoje-tech.com.
