Outdoor Parking Guidance Direction LED Display Screen

Outdoor Parking Guidance Direction LED Display Screen

1.Model:ZOJE-OA31-1D
2.Digital & arrow display. Guides fast
3.Smooth parking flow , parking space utilization
4.Clear visibility under strong outdoor light、day and night
5.Modular design, easy assembly
6.Real-time data sync. Links system to update vacancy status instantly
7.Adapts to outdoor temperature changes
8.24/7 tech support and service
  • Face to Face Discussion
  • Quality Assurance
  • 24/7 Customer Service

Product Introduction

Outdoor Parking Guidance Direction LED Display Screen for Smart Parking Systems

ZOJE Intelligent Technology builds the Outdoor Parking Guidance Direction LED Display Screen (Model: ZOJE-OA31-1D). It sits in the industrial-grade variable message sign group. parking guidance systems use it to send drivers to free spaces. Arrows show the way, and a number tells how many spots are still open. Output reaches 7,000+ nits. On the front panel you get an IP65 rating. Working range runs from -30°C to +75°C. The display stays easy to read at any hour and in any season.

What This Display Does and How It Works

Inside an Intelligent Parking Guidance System (IPGS), this screen does the job of a specialized variable message sign (VMS). Don't mistake it for a standard digital billboard.

Live data arrives from ultrasonic sensors, magnetic sensors or camera-based detectors. TCP/IP or RS485 protocols carry that data along. The screen then shows moving arrows and slot counts at lot entrances and at key decision points inside the facility. Status messages such as "FULL" or "OPEN" go up too.

Circling the lot happens less. At peak hours, entry points stay clearer. Better use gets made of open spaces. For parking operators, that is what it comes down to.

Key Features

  • Digital + Arrow Display: Combines numerical vacancy count with directional arrows for fast, clear guidance
  • High Brightness: the output begins at 5,000 nits. From there it climbs to 10,000 nits. LEDs come in DIP or SMD3535 versions
  • Auto Dimming: a light sensor sits inside the unit and shifts the brightness on its own. At night you get no glare
  • Wide Viewing Angle: side to side the screen shows at 110° and up and down at 60°. Every lane still reads it clearly
  • Modular Design: One module can be swapped on its own. There is no need to take off the whole cabinet
  • Real-Time Data Sync: Fresh data lands in under 0.5 seconds. Vacancy status shows up right away
  • All-Weather Operation: From -30°C to +75°C, it keeps working. Internal heating and convection cooling keep it running.
  • Corrosion-Resistant Chassis: The frame is cold-rolled steel or anodized aluminum. An electrostatic powder coating sits on top.

Technical Specifications

Parameter Specification
Model ZOJE-OA31-1D
Communication Mode RS485
Communication Distance ≤300m
Light Source Red Highlight LED
Power Supply AC 110~240V
Power Consumption ≤50W (one-way)
Protection Level IP65
Frame Material Aluminum alloy
Carton Dimensions (One layer) 690×210×65mm
Carton Dimensions (Two layers) 690×370×65mm
Carton Dimensions (Three layers) 690×530×65mm

Outdoor Application Scenarios

Municipal and Airport Parking Hubs

These screens serve as Level 1 guidance nodes at entry points in multi-level terminals and transport hubs. Traffic gets sent into set availability zones. Refresh rates hold under 0.5 seconds. Redundant power supply setups are supported too.

Commercial Real Estate and Outdoor Parking Guidance Direction LED Display Screen Mixed-Use Complexes

Shopping malls and office towers can run this screen at P4 to P10 pixel pitch. That way the display shows vacancy counts along with other status information. Hooked up to license plate recognition (LPR) systems, it also sends vehicles toward reserved zones.

Coastal and Industrial Open-Air Lots

Salt air and industrial pollutants damage electronics fast. The aluminum cabinetry here is fully sealed, and the PCBs carry a conformal coating. Oxidation and circuit failure stay away from internal components. That holds up even in heavy rain, fog, or corrosive conditions.

application

Quality Control

Every unit goes through production testing before shipment.

  • IP Testing: Rain spray and dust chamber tests to verify IP65/IP54 protection ratings
  • 72-Hour Aging Test: The unit stays powered on in a continuous cycle. This catches parts that fail early and shows whether the PSU holds steady
  • Vibration and Impact Testing: Puts the unit through stress like shipping and wind loads
  • Optoelectric Calibration: Checks that brightness stays even within ±5%. Color temperature is confirmed at 6,500K–9,000K
  • Salt Spray Corrosion Test: a 48-hour run against the chassis coating and the PCB conformal coating

certification

Customization and OEM/ODM Options for Outdoor Parking Guidance Direction LED Display Screen

Hardware and software can both be customized by ZOJE to match project specs. What the display shows is not limited to standard arrows and numbers. You can set it to roll dynamic text, to flash alerts in Red, Green, or Amber, and to show emergency notices. Parking rates can go up there too, or a "Lot Closed" message.

OEM and ODM cooperation is available for parking system integrators and large-scale project contractors. Standard product lead time is 5–7 days; customized orders ship within 10–15 days.

About ZOJE

ZOJE Intelligent Technology holds ISO 9001:2015 certification. Its manufacturing facility runs in Shenzhen. Sea freight and air freight both carry the products, including the Outdoor Parking Guidance Direction LED Display Screen, under DDU and DDP trade terms.

FAQ

Q: How does the screen remain readable in direct sunlight?

A: SMD3535 or DIP LEDs put out up to 7,000+ nits of brightness. An ambient light sensor is built in and changes the output on its own. At midday the display stays legible. At night it keeps the brightness from going too high.

Q: What communication protocols does it support?

A: TCP/IP and RS485 both work on this display. There is also an open SDK/API. That lets the display link up with third-party Parking Management Systems (PMS), ultrasonic sensors, and loop detectors.

Q: How does it handle extreme heat or freezing cold?

A: The parts are industrial-grade. That gives a range of -30°C to +75°C. In cold weather, internal heating elements stop freezing and condensation. In hot weather, convection heat sinks and active cooling keep the temperature down.

Q: How long should the unit last in service?

A: MTBF is rated past 100,000 hours. Upkeep is simple. Wipe the front mask from time to time, and check the waterproof seals. Each module comes out on its own, so the cabinet never has to move.

Q: Could the content shown on the screen be changed?

A: Yes. Dynamic text rolling is supported on this controller. So are variable colors and simple graphics. Beyond the standard arrows and numbers, operators can set parking rates, emergency alerts, or their own status messages.

Q: Can this display work with the parking management systems we already have?

A: Yes. Support for Modbus and MQTT protocols, along with an open SDK/API, allows integration with most existing parking management platforms and sensor networks.
